Solar LED Road Stud — Active Pavement Marker
Solar LED Road Stud — Active Pavement Marker
Solar-powered Active Road Stud With Embedded LEDs That Illuminate At Dusk — Equivalent To An "active Cat's Eye" Or "active Pavement Marker" For High-traffic And Rural Roads Where Ambient Light Is Poor. Day-charged, Dusk-to-dawn Operation. JKR-compliant Retroreflective When LEDs Are Off. Ideal For Federal Highways, State Roads, And Accident-prone Curves Where Passive Reflectors Give Insufficient Warning. Bahasa Malaysia: Penanda Jalan Solar LED.
Details
Brief Introduction
Solar road studs are raised pavement markers paved along road markings. Powered by solar energy and equipped with active lighting, they are particularly effective at night and in rainy or foggy weather. Their core function is to reveal the road outline to drivers, enhancing traffic safety.
Key Specifications
- Energy saving — low power consumption, solar-powered, lower running cost than conventional studs.
- Excellent warning effect — Taiwan wafer-chip LEDs deliver bright, dynamic active warning.
- Stable performance — integrated circuit design with heat-resistant rechargeable battery for long lifespan and reliable operation.
- Firm and durable — single-press moulded outer casing improves compression resistance.
- Long working time — 180 hours flashing or 40 hours steady on a full charge.
Technical Data
| Shell material | Cast aluminium |
|---|---|
| Solar panel | Mono-crystalline, 2 V / 0.3 W |
| Battery | 1.2 V / 600 mAh NiMH (anti-high/low temperature) |
| Battery lifetime | > 3 years |
| Running hours | 180 h flashing / 40 h steady (fully charged) |
| Working mode | Flashing 90 ± 10 times/min, or steady |
| Colours available | Red, yellow, blue, white, green |
| LED quantity | Single side: 2 LEDs · Double sides: 4 LEDs |
| Visibility | > 800 m |
| Lighting control | Light-sensor controlled (< 50 Lux) |
| Working temperature | -25°C to +75°C |
| Protection rating | IP68 |
| Compressive capacity | 20 tons |
